Narrow Gap Orbital MIG Welding Machine With Water Cooling Method

Description

This system is a special system designed for the welding of large and thick-walled structural parts. The weldable wall thickness range is 30~250mm; it can weld carbon steel, stainless steel and other materials; Fusion, deep protection. Continuous multi-layer multi-pass welding, high reproducibility, to achieve ideal welding results. Mainly used in coal machinery, energy and other industries.


Suitable for narrow groove welding of more than 9mm;

The special welding wire swing technology makes both sides of the groove fully welded;

High deposition efficiency, low heat input;

Using fixed position welding;

Multi-channel water cooling protection for welding torch, high duty cycle;

Double gas protection;

Suitable for welding of carbon steel, stainless steel and other materials;


Technical parameter
Narrow Gap MIG Welding System

Bevel form

U type, J type

Weldable pipe thickness (mm)

30-250

Weldable groove width (mm)

9-20

Maximum welding current(A)

350

Maximum wire feed speed(mm/min)

240000

Wire diameter (mm)

1.0-1.2

Protective gas

Mixed composition

Cooling method

Water cooling

Weight kg

5

Dimensions

320*200*600
